Features & Benefits
Improved Combustion
Quiet Performance
The Beckett RF Burner has increased air capacity and quiet operation.
Head Design
Burner head design ensures a stable flame base for all fuels and reduces coking.
State-of-the-Art Airflow
The Beckett RF Burner airflow design boosts velocity by utilizing the whole air tube, resulting in better combustion with optimized air flow.
Air Intake
The fuel pump is separated from the fresh air intake, improving burner performance during cold air intake.
Adjustable Flange
Burner-in-a-box provides an adjustable flange with a 2° pitch built-in for optimal performance.
Increased Air Capacity
Highly adjustable with air guides, adjustable head setting, and single air adjustment band.
Versatility
Fuel Agnostic Combustion Technology (F.A.C.T.)
Easily transitions between No. 2 and B100/R100 fuel types.
System Flexibility
Approved specs operate in various scenarios; tested with #2 and up to B100 fuel oil, with and without baffles, direct and chimney vents.
Outside Air Adapter
Allows ducting from virtually any direction.
Air Proving Kit
The air proving switch kit easily adds combustion air proving (CAP) to any Beckett RF Burner installation.
Flame Shaping
Nozzle line assembly and airflow adjustments provide more effective flame shaping through two distinct adjustments.
Flame Sighting
The Beckett RF Burner cad cell’s position offers greater tolerance and reduced position sensitivity
Ease of Use
Optimized Air Intake Design
Features a built-in fresh air intake system, isolated from the pump bleed port, reducing the risk of oil entering the burner housing.
Air Adjustment with Ducting
Easily and accurately adjust air with the ducting in place, without needing to remove a cover.
Readily Available Beckett Parts
Utilizes the same major component parts found on other Beckett burners.
Optimized Design for User Simplicity
The z-dimension is easily set by inserting the nozzle line flush with the end of the air tube.
Ease of Access to Service
The control and igniter mounted on a single plate simplify nozzle line access and offer wide-open access to the burner interior and wiring.
Technical Specifications
Capacity
- 0.38 to 1.75 GPH
- 56,000 to 420,000 BTU/Hr
Fuels
- ASTM D396 FOR #1 & #2 Heating oil
- ASTM D396 for B6 – B20 Biodiesel blends
- ASTM D6751 for B100
- ASTM D975 for Diesel Fuel and Renewable Diesel
- CAN / CGSB – 3.2 for Heating Oil Types #0, #1, and #2
Standard Components
Motor
- 1/7 HP 3450 RPM Type PSC
Igniter
- Beckett PowerLight® Solid state
- Rated for continuous duty
Fuel Pump
- Beckett CleanCut® PF2032x: Single Stage
- Beckett CleanCut® 2-Stage Available: Contact Factory
Control
- Beckett GeniSys® 7565 120V Advanced Oil Burner Control with myTechnician app for programming and diagnostics
Electrical Characteristics
- Power Supply: 120 VAC / 60Hz
- Operating Load:
- 5.8 Amps maximum
- 240 VAC – Available (Contact factory)
Dimensions (Standard)
- Height: 10.900″
- Width: 13.700″
- Depth: 9.835″
Side View | Less Air Intake Cover
Side View | With Air Intake Cover
Rear View | Less Air Intake Cover
Ordering Information
Beckett RF Oil, Biodiesel, and Renewable Diesel Universal Burners
Built with a 2 degree pitched flange
Part No. | Description | GPH Range | Air Guide Installed |
---|---|---|---|
RF101 | 7" Air Tube with Adjustable Flange | 0.38 - 1.25 | White 2.0" Diameter - Universal |
RF102 | 7" Air Tube with Adjustable Flange | 1.00 - 1.75 | Blue 2.5" Diameter - Universal |
Air Guides
Red, White, and Blue air guides are included with Universal Burners
Part Number | Description | Feature |
---|---|---|
33232-001U | Red — 1.5" Diameter - Low Rate / Low Air | Enhances air adjustability for low firing rates and natural draft applications |
33232-002U | White — 2.0" Diameter - Universal | Works in most applications (Mounted in Universal Burners) |
33232-003U | Blue — 2.5" Diameter - High Rate / High Air | Increases air capacity for high firing rates and positive pressure appliances |
Beckett RF Burner Accessories
Part Number | Description | Feature |
---|---|---|
51633U | Adjustable Flange with a 0 Degree Pitch | Used when no pitch is needed |
51634U | Adjustable Flange with a 2 Degree Pitch | Standard for the RF Burner (Included with Universal Burners) |
52683U | Air Proving Switch Kit | 0.50" Water Column (Standard) |
52683-002U | Air Proving Switch Kit | 0.25" Water Column (Optional for high rate) |
52682U | Outside Air Adapter Kit for Beckett RF Burner | 3" Galvanized Adjustable Elbow, 4"x3" Galvanized Reducer, 4" Fresh Air Intake Hood |
Featured Associated Components
Replacement Parts
Click below to view all replacement parts in table form or hover over red number callouts in exploded views below to see part numbers that correspond to each callout.
Replacement Parts | ALL
The list below details all available replacement parts for the Beckett RF Burner. Please see other tabs for exploded view breakdowns of various components.
Item | Part No. | Description |
---|---|---|
1 | 4439U | SCREW 1/4-20 X 1/2" HEX HEAD (12 PACK) |
2 | VARIOUS | AIR TUBE SUBASSEMBLY |
3 | 3380U | FLANGE GASKET |
4 | 33237U | INTAKE COVER WITH GROMMETS |
5 | 52663-002U | CHASSIS SUBASSEMBLY (WITH AIR GUIDE KIT) |
6 | 7565U | CONTROL 120V |
7 | 4605-001U | #8-32 X 1/4" HEX HEAD SCREW (24 PACK) |
8 | 4586-002U | #6-32 X 1/4" HEX HEAD SCREW (24 PACK) |
9 | 33223U | ESCUTCHEON PLATE |
10 | VARIOUS | NOZZLE |
11A | 52671-001U | NOZZLE LINE ELECTRODE ASSEMBLY 5" SERIES |
11B | 52671-002U | NOZZLE LINE ELECTRODE ASSEMBLY 7" SERIES |
11C | 52671-003U | NOZZLE LINE ELECTRODE ASSEMBLY 9" SERIES |
12 | 3666U | SPLINE NUT |
13 | 4606-001U | SCREW #6-32 TORX BUTTON HEAD (12 PACK) |
14 | 33224U | ESCUTCHEON GUIDE BAR |
15 | PF20322U or PF20323 | B100 CLEANCUT PUMP SINGLE STAGE 120V |
16 | 33230U | AIR INLET BODY |
17 | 21808U | PUMP CORDSET, NON-DELAY |
18 | 4595-001U | THUMBSCREW (3 PACK) |
19 | 4601-001U | WAVE SPRING (10 PACK) |
20 | 33218U | AIR BAND |
21 | 4596U | BARREL NUT (25 PACK) |
22 | 4603-001U | #10-24 X 1/2" SCREW FLAT HEAD TORX (24 PACK) |
23 | 4466U | #10-24 X 3/8" HEX HEAD SCREW (24 PACK) |
24 | 33231U | AIR BOOT BACK COVER |
25 | 4602-001U | #6-32 X 3/8" SCREW (12 PACK) |
26 | 33210GYU | HOUSING PUMP HALF PAINTED |
27A | 33232-001U | RED AIR GUIDE (LOW RATE/LOW AIR) |
27B | 33232-002U | WHITE AIR GUIDE (UNIVERSAL) |
27C | 33232-003U | BLUE AIR GUIDE (HIGH RATE/HIGH AIR) |
28 | 4605-001 | #8-32 X 1/4" HEX HEAD SCREW (24 PACK) |
29 | 2801U | PUMP COUPLING 3-5/8" |
30 | 4604-001U | FLAT HEAD SCREW (24 PACK) |
31 | 33222U | OIL LINE SLOT COVER |
32 | 33209GYU | HOUSING MOTOR HALF PAINTED |
33 | 4607-001U | 1/4-20 X 3/4" CARRIAGE BOLT (10 PACK) |
34 | 65003U | WARNING LABEL (10 PACK) |
35 | 2W10423U | 1/8" NPT PLUG SOCKET DRIVE (12 PACK) |
36 | 33235U | PIVOT, LOCK KNOB |
37 | 21837U | BLOWER WHEEL 4-3/4" X 2-7/16" |
38 | 33240U | SPACER (25 PACK) |
39 | 4189U | SCREW 1/4-20 X 7/8" HEX HEAD (12 PACK) |
40 | 21805U | 1/7 HP MOTOR, 120V/60HZ 3450 RPM |
41 | 4466U | #10-24 X 3/8" HEX HEAD SCREW (24 PACK) |
42 | 4584-001U | CABLE TIE (24 PACK) |
43 | 3741U | ELECTRICAL BOX, 4"X4" |
44 | 4231U | #10-32 X 3/8" GROUND SCREW (GREEN) |
45 | 21885U | STRAIN RELIEF (24 PACK) |
46 | 52662U | IGNITER SUBASSEMBLY (LESS CONTROL) |
47 | 4340U | 1/4-20 ACORN NUT (12 PACK) |
48 | 33245U | GASKET, UL94V-0 (12 PACK) |
49A | 52677U | RF3 HEAD ASSEMBLY (6-SLOT) |
49B | 52678U | RF4 HEAD ASSEMBLY (9-SLOT) |
50A | EA24306TU | ELECTRODE ASSEMBLY, 5"-6" AIR TUBES (2 PACK) |
50B | EA29406TU | ELECTRODE ASSEMBLY, 7"-8" AIR TUBES (2 PACK) |
50C | EA34807TU | ELECTRODE ASSEMBLY, 9"-10" AIR TUBES (2 PACK) |
51 | 149U | ELECTRODE CLAMP (2 PACK) |
52 | 4219U | 1/4-20 X 5/8" HEX HEAD SCREW (12 PACK) |
53A | 52670-001U | NOZZLE LINE SUBASSEMBLY KIT (5"-6" AIR TUBES) |
53B | 52670-002U | NOZZLE LINE SUBASSEMBLY KIT (7"-8" AIR TUBES) |
53C | 52670-003U | NOZZLE LINE SUBASSEMBLY KIT (9"-10" AIR TUBES) |
54 | INCLUDED IN 52670 KIT (AS REQ'D) | ELECTRODE SPACER |
55 | INCLUDED IN 52670 KIT (AS REQ'D) | 1/4-20 X 1/4" SET SCREW |
56 | INCLUDED IN 52670 KIT (AS REQ'D) | STATIC PLATE, 2-3/4" |
57 | INCLUDED IN 52670 KIT (AS REQ'D) | #8-18 X 7/16" HEX HEAD SCREW |
58 | 4454U | #10-16 X 1/2" HEX HEAD SCREW (24 PACK) |
59 | 52437-003U | 120V IGNITER W/BRASS TERMINALS & GASKET |
60 | 52672BKU | IGNITER CONTROL PLATE, BLACK W/LABEL |
61 | 5963008U | RF DETECTOR ASSEMBLY |
4439U
SCREW 1/4-20 X 1/2" HEX HEAD (12 PACK)
VARIOUS
AIR TUBE SUBASSEMBLY
3380U
FLANGE GASKET
33237U
INTAKE COVER WITH GROMMETS
52663-002U
CHASSIS SUBASSEMBLY (WITH AIR GUIDE KIT)
7565U
CONTROL 120V
4605-001U
#8-32 X 1/4" HEX HEAD SCREW (24 PACK)
4586-002U
#6-32 X 1/4" HEX HEAD SCREW (24 PACK)
33223U
ESCUTCHEON PLATE
VARIOUS
NOZZLE
52671-001U
NOZZLE LINE ELECTRODE ASSEMBLY 5" SERIES
52671-002U
NOZZLE LINE ELECTRODE ASSEMBLY 7" SERIES
52671-003U
NOZZLE LINE ELECTRODE ASSEMBLY 9" SERIES
3666U
SPLINE NUT
PF20322U or PF20323
B100 CLEANCUT PUMP SINGLE STAGE 120V
33230U
AIR INLET BODY
21808U
PUMP CORDSET, NON-DELAY
4595-001U
4595-001U THUMBSCREW (3 PACK)
4595-001U
4595-001U THUMBSCREW (3 PACK)
4601-001U
WAVE SPRING (10 PACK)
33218U
AIR BAND
4596U
BARREL NUT (25 PACK)
4603-001U
#10-24 X 1/2" SCREW FLAT HEAD TORX (24 PACK)
4466U
#10-24 X 3/8" HEX HEAD SCREW (24 PACK)
33231U
AIR BOOT BACK COVER
4602-001U
#6-32 X 3/8" SCREW (12 PACK)
33210GYU
HOUSING PUMP HALF PAINTED
AIR GUIDES
33232-001U: RED AIR GUIDE (LOW RATE/LOW AIR)
33232-002U: WHITE AIR GUIDE (UNIVERSAL)
33232-003U: BLUE AIR GUIDE (HIGH RATE/HIGH AIR)
4605-001
#8-32 X 1/4" HEX HEAD SCREW (24 PACK)
2801U
PUMP COUPLING 3-5/8"
4604-001U
FLAT HEAD SCREW (24 PACK)
33222U
OIL LINE SLOT COVER
33209GYU
HOUSING MOTOR HALF PAINTED
4607-001U
1/4-20 X 3/4" CARRIAGE BOLT (10 PACK)
65003U
WARNING LABEL (10 PACK)
2W10423U
1/8" NPT PLUG SOCKET DRIVE (12 PACK)
33235U
PIVOT, LOCK KNOB
21837U
BLOWER WHEEL 4-3/4" X 2-7/16"
33240U
SPACER (25 PACK)
4189U
SCREW 1/4-20 X 7/8" HEX HEAD (12 PACK)
4189U
SCREW 1/4-20 X 7/8" HEX HEAD (12 PACK)
21805U
1/7 HP MOTOR, 120V/60HZ 3450 RPM
4466U
#10-24 X 3/8" HEX HEAD SCREW (24 PACK)
4584-001U
CABLE TIE (24 PACK)
3741U
ELECTRICAL BOX, 4"X4"
4231U
#10-32 X 3/8" GROUND SCREW (GREEN)
21885U
21885U STRAIN RELIEF (24 PACK)
52662U
IGNITER SUBASSEMBLY (LESS CONTROL)
4340U
4340U 1/4-20 ACORN NUT (12 PACK)
33245U
GASKET, UL94V-0 (12 PACK)
HEAD ASSEMBLY
52677U: RF3 HEAD ASSEMBLY (6-SLOT)
52678U: RF4 HEAD ASSEMBLY (9-SLOT)
ELECTRODE ASSEMBLY
EA24306TU: ELECTRODE ASSEMBLY, 5"-6" AIR TUBES (2 PACK)
EA29406TU: ELECTRODE ASSEMBLY, 7"-8" AIR TUBES (2 PACK)
EA34807TU: ELECTRODE ASSEMBLY, 9"-10" AIR TUBES (2 PACK)
149U
ELECTRODE CLAMP (2 PACK)
4219U
1/4-20 X 5/8" HEX HEAD SCREW (12 PACK)
NOZZLE LINE SUBASSEMBLY
52670-001U: NOZZLE LINE SUBASSEMBLY KIT (5"-6" AIR TUBES)
52670-002U: NOZZLE LINE SUBASSEMBLY KIT (7"-8" AIR TUBES)
52670-003U: NOZZLE LINE SUBASSEMBLY KIT (9"-10" AIR TUBES)
INCLUDED IN 52670 KIT (AS REQ'D)
ELECTRODE SPACER
INCLUDED IN 52670 KIT (AS REQ'D)
1/4-20 X 1/4" SET SCREW
INCLUDED IN 52670 KIT (AS REQ'D)
STATIC PLATE, 2-3/4"
INCLUDED IN 52670 KIT (AS REQ'D)
#8-18 X 7/16" HEX HEAD SCREW
Downloads & Links
RF Burner Accessories Product Sheets
Additional Resources
Warnings (prop65)
Warranty
Please note, all warranty claims must be initiated through an authorized Beckett supplier/distributor. Distribution policies will not allow Beckett to directly handle warranty claims with installers and/or consumers.
