Details
Features
- 20kV peak rating guarantees quick and efficient ignition
- External heat sink eliminated for improved performance and reduced frequency of replacement due to overheating and arcing
- Lightweight, single piece design is compatible with Beckett and other burners to reduce required inventory
- Weighs less than 1 lbs versus an 8 lbs iron core transformer, making shipping and installation easier
- Fully potted with improved epoxy to withstand thermal shock and protect electronic components; waterproof
- Simplified wiring requirements and fewer wires for ease of installation
- A vacuum encapsulation process, using epoxy, provides resistance to moisture, excellent heat dissipation and electrical insulation
- Case material is high-temperature thermoplastic that provides high impact strength, scratch resistance, impenetrable to oil and most chemicals
- Adapts to multiple baseplates – making it the most versatile unit
on the market - Epoxy potting will not shrink or crack like tar-filled transformers
Technical Specifications
- Input Voltage: 10.8 – 16 Vdc
- Output Voltage: 20kV peak
- Output Current: 25 mA RMS
- Input Current: 2.5 A Maximum
- Ambient Operating Temperature: -40°F (-40°C) to 150°F (66°C)
- Storage Temperature: -40°F (-40°C) to 150°F (66°C)
- Moisture: 5 to 95% Relative Humidity
Dimensions
PowerLight Igniter Kits
Igniter | Description | Replaces |
5270001U | Beckett ADC 12 Vdc | 5218301U |
5270002U | Beckett SDC 12 Vdc | 5218303U |
5270003U | Wayne MSRDC | 5218307U |
5270004U | Wayne E | 5218305U |
5270005U | Igniter only | 5218309U |
PowerLight Igniter Baseplate Kits
Kit Part Number | Application |
51830U | Beckett A Housing |
51831U | Beckett S Housing |
51833U | Wayne E |
51829U | Wayne M |
Downloads & Links
Product Sheets
12 Vdc PowerLight Product Sheet
Instructions
12 Vdc PowerLight Igniter Instructions
Important Notices
Warnings (prop65)
Warranty
Please note, all warranty claims must be initiated through an authorized Beckett supplier/distributor. Distribution policies will not allow Beckett to directly handle warranty claims with installers and/or consumers.
